Structural Bulb Blind Rivet

Large blind side bearing area- Spreads clamp load over a large area. - Ideal for thin, brittle and soft sheet materials.

Good multi-grip performance - Simplifies stock control. - Reduces operator error. - Accommodates a wide variety of material thicknesses.

Positively retained stem - Secure, vibration resistant joint.

Wide choice of purposed designed installation tools - Maximum production flexibility


Material

Body

Aluminum 5052

Finish

Polished, Painted

Mandrel

Aluminum

Finish

Polished

Head Type

Dome, Large Flange


Size

Drill

L

Grip Range

dk

K

dm

max

max

max

max

4.0
(5/32")


16.0

1.0-3.0

8.2

1.6

2.3

21.2

1.0-7.0

8.2

1.6

2.3

4.8
(3/16")


18.1

1.0-4.0

10.1

2.1

2.9

23.3

1.0-9.0.8

10.1

2.1

2.9

27.1

4.0-12.0

10.1

2.1

2.9
