Material: Aluminum, Steel, Stainless steel
CODE | Size | Grap Range | Length | D。 | D | dk | K | L | |
FM3 | FM3R | M3 | 0.5～2.0 | 4.5 | 5 | 5 | 7 | 0.8 | 8.8 |
FM4 | FM4R | M4 | 0.5～2.0 | 6.0 | 6 | 6 | 9 | 0.8 | 10.8 |
FM5 | FM5R | M5 | 0.5～2.5 | 7.0 | 7 | 7 | 10 | 1.0 | 13.0 |
FM6 | FM6R | M6 | 0.5～3.0 | 8.5 | 9 | 9 | 13 | 1.5 | 15.0 |
FM8 | FM8R | M8 | 0.5～3.5 | 11.0 | 11 | 11 | 15 | 1.5 | 18.0 |
FM10 | FM10R | M10 | 0.5～3.5 | 12.0 | 13 | 13 | 17 | 1.8 | 20.3 |
FM12 | FM12R | M12 | 0.5～3.5 | 16.0 | 15 | 15 | 19 | 1.8 | 24.3 |
